Trampoline Fabric Series

CSD-BC-1813-L03335

Colours(Customized):
This specification applies to product manufactured and is based on average value, for production reasons, there could appear slight deviations that do not affect the fabric quality. This specification intends to inform about our product without legal binding and is based on our most recent knowledge.

Technical Parameters

Material100% polypropylene
Weight265gsm
Width2.8/ 3.4/ 3.7/ 3.95/ 4.2/4.5m Customized
Thickness0.52 mm
Grab Tensile strengthASTM D4632

Warp: >484lbs (2100N)
Weft: >450lbs (2000N)

Apparent Breaking ElongationASTM D4632

Warp: 20%
Weft: 20%

Trapezoid Tear StrengthASTM D4533

Warp: 20%5lbs (910N)
Weft: 189lbs (840N)

Burst StrengthASTM D3786827 psi (5700kpa)
Abrasion ResistanceASTM D488695% strength retained
Puncture StrengthASTM D4833202lbs (900N)
UV ResistanceEN71-14:2014 and ISO 13934-1 After 1000h UV Exposure 90% strength retained
Phthlate FreeAfPS GS 2014:01 PAK, EN 14362-1:2012, ISO 17234-1:2010, EN 14362-3:2012, BS EN ISO 14184-1:2011, BS EN 71-3:2013+A1:2014 Safety of Toys
